Streamline Sheet Metal Management
MPI’s Pneumatic Automated Fanner Magnet is a cutting-edge solution to streamline high-volume sheet metal separation in fully automated production environments. Unlike conventional static fanners, this advanced system uses a pneumatically actuated mechanism to retract the magnet when not in use—eliminating residual magnetic fields for safer handling and more consistent sheet feeding. Engineered with rare earth magnet strength and precision automation, the PAFM is ideal for oily, sticky, polished, or pre-finished metal blanks used in stamping, forming, and shearing applications. Its compact design and custom mounting options allow seamless integration into robotic tooling and PLC-driven lines.
Benefits of the Pneumatic Automated Fanner Magnet From Magnetic Products, Inc
-
Pneumatically Retracting Magnet
The magnet retracts automatically to eliminate residual field, reduce double-sheet issues, and improve safety.
-
Rare Earth Magnetic Force
Strong and reliable rare earth magnet material ensures consistent fanning even for large or oily sheets.
-
Ideal for Automated Lines
Explicitly built for PLC-controlled systems, minimizing manual interaction and maximizing uptime.
-
Improves Sheet Separation
Efficiently separates oily, sticky, or pre-finished blanks where conventional fanners fail.
-
Compact and Lightweight Design
Allows easy mounting to robotic end-of-arm tooling or tight workspaces.
-
Enhanced Operator Safety
Automatic magnet retraction minimizes exposure to active magnetic fields.
-
Durable Construction
Available with steel or stainless-steel housings and replaceable wear strips for long-lasting performance.
-
Customizable Mounting Options
Optional pallet pin bracket and special mounting configurations for flexible installation.
Pneumatic Automated Fanner Magnet Product Details
Installation
Use the provided bracket or custom mounting plate to mount the PAFM to the robotic arm, tooling system, or line structure.
Initial Setup
Connect the unit to your facility’s pneumatic system and PLC controller for automated actuation.
Activation
When a new stack of metal sheets is presented, the PLC signals the unit to extend the magnet toward the stack.
Sheet Separation
The rare earth magnet induces “like” poles into the steel sheets, creating repelling forces that separate the sheets for easy pickup.
Automatic Retraction
Once the fanning is complete, the magnet retracts pneumatically away from the sheet stack, removing the magnetic field and allowing the top sheet to be removed cleanly.
Repeat Cycle
The system is ready for the next sheet stack without manual intervention, ensuring continuous, efficient operation.
Pneumatic Automated Fanner Magnet Specification Table
US Customary Units
| MODEL # | (B) FLOW OPENING (IN.) | (C) FLOW OPENING (IN.) | OVERALL LENGTH (IN) | APPROX. WEIGHT (LBS) | FLOW RATE (FT³/HOUR) |
|---|---|---|---|---|---|
| MC-808 | 8 | 8 | 12.25 | 154 | 1,200 |
| MC-810 | 10 | 8 | 14.25 | 192 | 1,500 |
| MC-812 | 12 | 8 | 16.25 | 231 | 2,000 |
| MC-1010 | 10 | 10 | 14.25 | 195 | 2,200 |
| MC-1012 | 12 | 10 | 16.25 | 233 | 2,500 |
| MC-1014 | 14 | 10 | 18.25 | 272 | 3,000 |
| MC-1016 | 16 | 10 | 20.25 | 311 | 3,500 |
| MC-1018 | 18 | 10 | 22.25 | 350 | 4,000 |
| MC-1020 | 20 | 10 | 24.25 | 389 | 5,000 |
| MC-1022 | 22 | 10 | 26.25 | 428 | 6,000 |
| MC-1024 | 24 | 10 | 28.25 | 467 | 7,000 |
| MC-1026 | 26 | 10 | 30.25 | 506 | 8,000 |
| MC-1028 | 28 | 10 | 32.25 | 545 | 10,000 |
| MC-1030 | 30 | 10 | 34.25 | 584 | 11,500 |
| MC-1032 | 32 | 10 | 36.25 | 622 | 13,300 |
| MC-1034 | 34 | 10 | 40.25 | 661 | 15,200 |
| MC-1036 | 36 | 10 | 42.25 | 700 | 17,000 |
